FiveM Blips: IDs, Sprites & Map Icons

FiveM blips are the icons on the GTA V pause map and minimap: hospitals, police stations, shops, garages and mission objectives. Choose a numeric sprite ID in the visual explorer, select a documented blip colour, and generate a client-side Lua or JavaScript snippet.

The reference below preserves 883 source sprite entries and 100 blip colour entries from the official game-build-3258 list. There are gaps in the sprite ID sequence; an absent ID is not an undocumented working sprite.

FiveM blip ID explorer and code generator

Explore all FiveM blip sprites

Find an icon visually, select its numeric ID, choose a colour and copy a working client-side snippet.

Download source JSON ↗

Search blipsSortSprite ID (ascending)Sprite ID (descending)Name (A–Z)ViewVisual gridCompact list

☆ Favorites (0)883 of 883 sprites · 100 source colour entries

Selected sprite · ID 61

radar_hospital

Copy ID☆ Save

Sprite images are unmodified source previews. The selected colour is shown as a swatch, not a promise of exact in-game tinting.

Colour 2: Green

Blip code generator

client.lua or client.js · works without a framework or external dependencies.

Blip labelColour ID0 — White1 — Red2 — Green3 — Blue4 — White5 — Yellow6 — Light Red7 — Violet8 — Pink9 — Light Orange10 — Light Brown11 — Light Green12 — Light Blue13 — Light Purple14 — Dark Purple15 — Cyan16 — Light Yellow17 — Orange18 — Light Blue19 — Dark Pink20 — Dark Yellow21 — Dark Orange22 — Light Gray23 — Light Pink24 — Lemon Green25 — Forest Green26 — Electric Blue27 — Bright Purple28 — Dark Yellow29 — Dark Blue30 — Dark Cyan31 — Light Brown32 — Light Blue33 — Light Yellow34 — Light Pink35 — Light Red36 — Beige37 — White38 — Blue39 — Light Gray40 — Dark Gray41 — Pink Red42 — Blue43 — Light Green44 — Light Orange45 — White46 — Gold47 — Orange48 — Brilliant Rose49 — Red50 — Medium Purple51 — Salmon52 — Dark Green53 — Blizzard Blue54 — Oracle Blue55 — Silver56 — Brown57 — Blue58 — East Bay59 — Red60 — Yellow Orange61 — Mulberry Pink62 — Alto Gray63 — Jelly Bean Blue64 — Dark Orange65 — Mamba66 — Yellow Orange67 — Blue68 — Blue69 — Green70 — Yellow Orange71 — Yellow Orange72 — Transparent Black73 — Yellow Orange74 — Blue75 — Red76 — Deep red77 — Blue78 — Oracle Blue79 — Transparent Red80 — Transparent Blue81 — Orange82 — Light Green83 — Purple84 — Blue85 — Transparent BlackScale: 0.8X coordinateY coordinateZ coordinate

Show only nearby (short range)Show GPS route

LuaJavaScript

Copy code

-- client.lua · Run this in a client script
local blip = AddBlipForCoord(307.7, -595.2, 43.3)
SetBlipSprite(blip, 61)
SetBlipColour(blip, 2)
SetBlipScale(blip, 0.8)
SetBlipDisplay(blip, 4)
SetBlipAsShortRange(blip, true)
BeginTextCommandSetBlipName("STRING")
AddTextComponentString("Hospital")
EndTextCommandSetBlipName(blip)

-- Remove only the blip owned by this resource when it stops.
AddEventHandler('onResourceStop', function(resourceName)
    if resourceName == GetCurrentResourceName() and DoesBlipExist(blip) then
        RemoveBlip(blip)
    end
end)

Place the code in a client script declared in your fxmanifest.lua. Replace the example coordinates; the generated code cleans up its own blip on resource stop.

All sprite IDs

0 radar_higher☆

1 radar_level☆

2 radar_lower☆

3 radar_police_ped☆

4 radar_wanted_radius☆

5 radar_area_blip☆

6 radar_centre☆

7 radar_north☆

8 radar_waypoint☆

9 radar_radius_blip☆

10 radar_radius_outline_blip☆

11 radar_weapon_higher☆

12 radar_weapon_lower☆

13 radar_higher_ai☆

14 radar_lower_ai☆

15 radar_police_heli_spin☆

16 radar_police_plane_move☆

27 radar_mp_crew☆

28 radar_mp_friendlies☆

36 radar_cable_car☆

37 radar_activities☆

38 radar_raceflag☆

40 radar_safehouse☆

41 radar_police☆

42 radar_police_chase☆

43 radar_police_heli☆

44 radar_bomb_a☆

47 radar_snitch☆

48 radar_planning_locations☆

50 radar_crim_carsteal☆

51 radar_crim_drugs☆

52 radar_crim_holdups☆

54 radar_crim_player☆

56 radar_cop_patrol☆

57 radar_cop_player☆

58 radar_crim_wanted☆

Browse all 100 documented colour entries (including friendly/enemy variants)

Variant colours share a numeric ID. The official reference uses SET_BLIP_AS_FRIENDLY for friendly/enemy state; they are not separate IDs for SetBlipColour.

0 · White

1 · Red

2 · Green

2 (variant) · Red

2 (variant) · Blue

3 · Blue

3 (variant) · Red

4 · White

4 (variant) · Red

4 (variant) · Blue

5 · Yellow

5 (variant) · Red

5 (variant) · Blue

6 · Light Red

7 · Violet

8 · Pink

9 · Light Orange

10 · Light Brown

11 · Light Green

12 · Light Blue

13 · Light Purple

14 · Dark Purple

15 · Cyan

16 · Light Yellow

17 · Orange

18 · Light Blue

19 · Dark Pink

20 · Dark Yellow

21 · Dark Orange

22 · Light Gray

23 · Light Pink

24 · Lemon Green

25 · Forest Green

26 · Electric Blue

27 · Bright Purple

28 · Dark Yellow

29 · Dark Blue

30 · Dark Cyan

31 · Light Brown

32 · Light Blue

33 · Light Yellow

34 · Light Pink

35 · Light Red

36 · Beige

37 · White

38 · Blue

39 · Light Gray

40 · Dark Gray

41 · Pink Red

42 · Blue

43 · Light Green

44 · Light Orange

45 · White

46 · Gold

47 · Orange

48 · Brilliant Rose

49 · Red

49 (variant) · Blue

50 · Medium Purple

51 · Salmon

52 · Dark Green

53 · Blizzard Blue

54 · Oracle Blue

55 · Silver

56 · Brown

57 · Blue

58 · East Bay

59 · Red

60 · Yellow Orange

61 · Mulberry Pink

62 · Alto Gray

63 · Jelly Bean Blue

64 · Dark Orange

65 · Mamba

66 · Yellow Orange

66 (variant) · Red

66 (variant) · Blue

67 · Blue

67 (variant) · Red

68 · Blue

68 (variant) · Red

69 · Green

69 (variant) · Red

69 (variant) · Blue

70 · Yellow Orange

71 · Yellow Orange

72 · Transparent Black

73 · Yellow Orange

74 · Blue

75 · Red

76 · Deep red

77 · Blue

78 · Oracle Blue

79 · Transparent Red

80 · Transparent Blue

81 · Orange

82 · Light Green

83 · Purple

84 · Blue

85 · Transparent Black

Source: official Cfx.re blips, game build 3258, imported 2026-09-23. Sprite IDs are not contiguous; missing IDs were not invented. This reference is for GTA V / FiveM, not RedM.

How to create a FiveM map blip

Blips for the local player map are created in a client script, not in server.lua. For a hospital example, put this in client.lua:

local blip = AddBlipForCoord(307.7, -595.2, 43.3)
SetBlipSprite(blip, 61) -- radar_hospital
SetBlipColour(blip, 2) -- Green
SetBlipDisplay(blip, 4)
SetBlipScale(blip, 0.8)
SetBlipAsShortRange(blip, true)

BeginTextCommandSetBlipName("STRING")
AddTextComponentString("Hospital")
EndTextCommandSetBlipName(blip)

AddEventHandler('onResourceStop', function(resourceName)
    if resourceName == GetCurrentResourceName() and DoesBlipExist(blip) then
        RemoveBlip(blip)
    end
end)

AddBlipForCoord creates the handle; SetBlipSprite chooses the map icon, and SetBlipColour sets a value from the separate colour table. SetBlipAsShortRange limits nearby minimap display, while SetBlipRoute(blip, true) adds GPS routing. The generator above provides JavaScript and cleanup code too.

Why is my blip invisible or wrong?

• Wrong ID: 1 is radar_level in the official sprite list, not a generic circle. Use the exact numeric sprite ID.
• No map icon: Confirm your client script is declared in the client_scripts section of fxmanifest.lua, and that the resource is started.
• Unexpected colour: Colour IDs are not sprite IDs. Friendly/enemy variants may depend on SET_BLIP_AS_FRIENDLY rather than a separate SetBlipColour value.
• Wrong position: Use actual world coordinates instead of undefined x, y, z variables.
• Duplicate icons: Create each destination blip once and retain its handle. Do not recreate blips every frame.

Related: FiveM Natives, resource lifecycle, markers, and the official blip reference .

Source scope and usage notes

The source identifies game build 3258. Sprite IDs are not a consecutive list: omitted IDs stay omitted. Color IDs are a separate namespace, and friendly/enemy variants can share a numeric ID. Animated previews are kept as their original GIF files.

Images are served from this repository, not hotlinked. Empty source fields and unknown identifiers are retained as unknown. View the official source  or download the complete dataset.
